How to:
ENVI-MAG Manual A4-5
Setup
How to:
Access the main operating display
The main operating display can be called up by simply pressing the “ON” key or
by pressing the “ESCAPE” key one or more times.
Access display sub-panels/blocks
Some display screens have sub-panels or blocks that are separated by a vertical
and/or horizontal line. These represent different logical sub-groups of informa-
tion. To move the cursor into another block, you will have to press the “NEXT” key.
Access the parameter fields
To access a particular parameter field, move the cursor by repeatedly pressing
either of the cursor (← →) keys until the cursor is on the desired field.
Change parameters
There are two types of parameters—those that are selected from a list and those
that you must fill-in a value. The proper method for changing a particular item is
indicated by the prompt at the left-hand, bottom corner of the display.
Changing the parameters requires you to either:
▲ select from a list when the prompt is Chg?+-, by pressing either the
“+” or “-” keys. Please see also “Select!” on page A4-6.
or
▲ fill in the parameter fields via the keypad when the prompt is
Chg?ENT, by first pressing the “ENTER” key. You will then need to
follow the procedures as described for “Enter!” on page A4-6.
q
or
0
t
23
=-
e
