Cable repair
ENVI-MAG Manual A7-7
Maintenance
Cable repair
Cables may occasionally need repair as conductors eventually break due to
flexing. Some connectors are sealed with a silicon compound to prevent the entry
of water and dirt. The sealing material can be removed after the cable clamp has
been unscrewed to get access to the pins. It is a good practice to tape up the
connector again when repaired. The proper connections are indicated in the
following table:
Cable Wire Color Connector Pin
Total Field
(780 547 & 780 550)
Shield/Bare K
White G
Gradiometer
(788 028)
Shield/Bare A
Green C
Red G
White H
Black K
Base Station
(780 546)
Shield/Bare A
White G
Black K
External Power
(788 029)
Red Outside
Black Center
