Preparation
A2-2 ENVI-MAG Manual
Figure A-2 The complete ENVI-MAG gradiometer kit
Unpacking
The standard ENVI-MAG is shipped in a durable cardboard box that should be
retained for storage and shipping. There is an optional carrying/shipping case
available as SCINTREX P/N 140 161. The ENVI-MAG with its accessories is
packaged in die-cut layers (slabs) of foam. This provides a proper place for every
item when you repack your instrument for shipping or storage. These foam layers
are disassembled in the following order, starting at the top:
Layer Description Contains
1
1inch (25mm) slab Full slab at top
2
2 inch (50mm) slab ENVI-MAG Console
Back Plate with harness
3
1inch (25mm) slab Full slab with cutout
4
2 inch (50mm) slab Staff
Standard Battery (1 or 2)
Cables
