Create a map
This menu selection gives you all the options needed to create and customize
your maps. The three options below the line on the right side of the menu screen
set parameters used by the
Draw the Map option.
Figure C-14 Selecting the map-making option
This is the basic map-making module. The options at this menu level allow you
to fine tune the appearance of your map.
Figure C-15 The main map-making dialogue screen
Draw the map
ENVIMAP Version 3.02.00
E N V I M A P
Instructions: 1. Use the cursor keys or mouse to highlight menu items.
2. Press Enter, or double-click mouse to select a menu
item and enter a dialogue entry screen.
3. Select dialogue items that you want to change.
4. Press Alt-H or click on Help for parameter help.
5. Press F1, Alt-L or click on LIST to display lists of
options or lists of files.
6. Press Alt-G or click on GO to complete a dialogue
entry screen.
System Configuration Draw the map
Prepare the data ------------------------
Create a map Map surround options
Plot Reference grid options
Contour options
Command Dos Help eXit
G:\ENVIMAP
ENVIMAP Version 3.02.00
Create a map.
This procedure will create "plot file" of the map. You may optionally
preview this file on a VGA screen and plot the file on you printer using
the "Plot" selection in the main menu.
Data file name:
↓
envimag.xyz
Field to plot: total field
Preview when done? YES
ground units: meters
Sheet orientation: Landscape
Title: ENVI-MAG Sample Data
Sub-Title: Sample Contour Map
Sub-Title: Test Survey
cleaR clear All Command Dos Help List eXit Go
