Menu Reference
ENVI-MAG Manual C3-15
Reference
Data File Name
The name of the XYZ file to be processed. A file list is available.
Field to Plot
You must specify either the Total magnetic field, the
Vertical gradient, or the Noise of the magnetic field to be
plotted. Please ensure that your choice is actually present in the data,
otherwise odd results may appear.
Preview when Done?
This is a simple YES or NO switch that will automatically display the
contour map on the screen once processing is finished.
Ground Units
You can either specify feet or metres as your ground units.
The following entries affect the appearance of your map.
Sheet Orientation
You can specify either a Landscape or Portrait orientation for your
output map sheet.
Title
This will be the main title of your map. It will be plotted in the centre
towards the bottom edge of your map sheet.
Sub-Title 1
This line will be plotted in a smaller size immediately below the Title
line.
Sub-Title 2
This line is plotted immediately below the previous sub-title line.
