ENVI-MAG Manual A4-25
Setup
Note entry
This section describes the steps needed to:
enter unique text to be recorded with the present measurement,
or how to enter text to be used as macros for use as quick-entry notes.
Identical keystrokes are also used to enter the operator’s name in the
previous paragraph.
Notes or macros may contain all letters and numbers as well as +,.,-. Entry
procedures are similar to the Enter! procedure for entering numbers only, as
discussed in previous sections. The Number keys now offer also three letters,
which can be accessed by subsequent keystrokes such as:
1 A B C 1...
The “CLEAR” key allows deletion of erroneous entries, whereas the “NEXT” key
allows spaces between words. New macros can be entered by simply over-writing
the previous ones.
The following steps enter the macro “fence 1” as Note 1. Other macros would be
entered similarly, except that they would be saved with Note 2, Note 3 etc.
From the Main operating display proceed as follows:
1. Press “NOTE” and the Note display appears.
NOTES: #nnnnnnnnnnnnnnnnnnnnnnnnnnnnnnnn
MACROS:
1:ccccccccccccccc 2: ccccccccccccccc
3:ccccccccccccccc 4: ccccccccccccccc
5:ccccccccccccccc
Chg?:ENT. BATT:bbb
2. Press the “ENTER” key.
3. Press the “2” key repeatedly until f appears.
w
6
e
2
