3.7.11 Selecting analog output values for RUN/STOP
transition
You can select the analog values that are output at the two
analog outputs when LOGO! changes from RUN mode to
STOP mode.
In the programming menu:
1. Move the “>” cursor to ’Edit..’: Press or
2. To accept ’Edit’: Press OK
3. Move the “>” cursor to ’AQ in Stop’: Press or
4. To accept ’AQ in Stop’: Press OK
LOGO! shows the following display:
>Defined
Last
AQ in Stop
Last
The current setting for the analog output channels is shown
on the bottom row. The default setting is ’Last’.
You can select either ’Last’ value (i.e. analog output values
are held at their last value) or ’Defined’ value (i.e. analog
output values are set to specific values). When LOGO!
changes from RUN mode to STOP mode, the values of the
analog outputs change as well, depending on the setting.
5. Select the desired output setting: Press or .
6. To confirm your entry: Press OK
Defining a specific analog output value
You want to output a specific analog value at the two
analog outputs.
1. Move the ’>’ cursor to ’Defined’: Press or
2. Confirm ’Defined’: Press OK
The display shows:
