LOGO! Manual
A5E00380835-01
164
Weekly timer: Example
The output of the weekly timer switch is to be set daily from
05:30 h to 07:40 h. The output should also be set every
Tuesday from 03:10 h to 04:15 h, and at the weekends
from 16:30 h to 23:10 h.
This requires three cams.
Here are the parameter assignment screen forms of the
cams No 1, 2 and 3, based on the timing diagram shown
earlier.
Cam1
Cam No1 must set the output of the weekly timer daily from
05:30 h to 07:40 h.
B1 1+
D=MTWTFSS
On =05:30
Off=07:40
Cam2
Cam No2 must set the output of the weekly timer every
Tuesday from 03:10 h to 04:15 h.
B1 2
D=–T–––––
On =03:10
Off=04:15
LOGO! functions
