6.3 Copying data from the LOGO! to the pro-
gram module (card)
To copy the circuit program to the program module (card):
1. Insert the program module (card) into the slot.
2. Switch the LOGO! to programming mode (ESC / >Stop).
>Program..
Card..
Setup..
Start
LOGO! main menu
3. The main menu opens. To select the ’Card’ command:
Press or
4. Press OK. The transfer menu opens.
> "Card
Card"
CopyProtect
= LOGO!
5. Move the ’>’ cursor to ’LOGO ³ Card’ (if required)
Press or
6. Press OK.
LOGO! now copies the circuit program to the program mod-
ule (card).
When LOGO! has finished copying, it automatically returns
you to the main menu:
>Program..
Card..
Setup..
Start
The circuit program backup is now stored on your program
module (card) and you can remove the card. Do not forget
to replace the cap.
LOGO! program module (card)
