Siemens LOGO! - A.6 Technical data: LOGO! 24 RC...

LOGO! Manual
A5E00380835-01
282
A.6 Technical data: LOGO! 24RC...
LOGO! 24RC
LOGO! 24RCo
Power supply
Input voltage 24 V AC/DC
Permissible range 20.4 ... 26.4 V AC
20.4 ... 28.8 V DC
Reverse polarity protection
Permissible mains frequency 47 ... 63 Hz
Power consumption
 24 V AC
 24 V DC
40 ... 110 mA
20 ... 75 mA
Voltage failure buffering typ. 5 ms
Power loss
 24 V AC
 24 V DC
0.9 ... 2.7 W
0.4 ... 1.8 W
Backup of the real-time clock
at 25 C
typ. 80 h
Accuracy of the real-time
clock
typ. 2 s / day
Digital inputs
Number 8,
optional P action or N action
Electrical isolation No
Input voltage L
 Signal 0 < 5 V AC/DC
g
 Signal 1 > 12 V AC/DC
Technical data
