Siemens LOGO! - Key Input Simulation in the Active Message Text

207
LOGO! Manual
A5E00380835-01
Press and to select the relevant line (you can only se-
lect lines that contain parameters). Press OK to change the
parameter. Use the keys , , and .
Confirm your changes with OK. You can now edit further
parameters in the message text (if any exist). Press ESC to
exit editing mode.
Key input simulation in the active message text
You can enable the four cursor keys C
, C , C  and
C  in an active message text by pressing ESC plus the
relevant cursor key.
Preset of the Par parameter
To configure the message text (programming mode):
..
..
..
..
Parameter assignment
screen form for Par
Press to select a line for the message text.
Press and to select the relevant type of message text
(Text, Par, Time...). Confirm with OK.
Further entries are required when “Text” or “Par” are se-
lected:
Press and to select the letter to be displayed in the
text. To move the cursor from one position to the other,
press and .
The list of available characters is here the same as for the
circuit program name. The character set is found in Chap-
ter 3.7.4.
Press OK to confirm your changes, and press ESC to exit
the editing mode.
To output a parameter (e.g. a process variable or function
value) as message text, select the relevant line with and
then press :
LOGO! functions
