LOGO! Manual
A5E00380835-01
236
5.1.1 Parameters
Note
In the following discourse on parameters, we presume that
the respective default parameter protection mode (”+”) has
been maintained. This is prerequisite for viewing and edit-
ing parameter in the parameter assignment mode!
See Chapter 4.3.5 and the example on Page 91.
Parameters are, for example:
The delay times of a timer relay.
The switching times (cams) of a timer switch.
Counter thresholds
The monitoring time for hour counters
The trigger thresholds.
Each one of the parameters is identified by its block num-
ber (Bx) and the shortname of the parameter. Examples:
T: ...is a configurable time.
MI: ...is a configurable time interval.
Note
LOGO!Soft Comfort also allows you to assign names to
blocks (for more information, refer to Chapter 7).
Confi
