Correlation between the password and the protective function
Password Protec-
tion
Editing Copying Deleting
– – Yes Yes Yes
Yes – Yes, with
password
Yes Yes, with
password
– Yes No No Yes
Yes Yes Yes, with
password
Yes, with
password
Yes, with
password
Assigning a security function
To assign a circuit program and copy protection function to
the program module (card), open the programming mode
and select “Card”.
1. Switch the LOGO! to programming mode (ESC / >Stop).
2. The main menu opens. To select the ’Card’ command:
Press or
3. To apply you entry in ’Card’: Press OK
4. Move the ’>’ cursor to ’CopyProtect’: Press or
5. To apply ’CopyProtect’: Press OK
LOGO! shows the following display:
>No
Yes
CopyProtect:
No
The current protection setting is shown in the bottom line.
This function is disabled by default (”No“: disabled).
LOGO! program module (card)
