Versions
The following LOGO! versions are available:
Symbol Designation Supply
voltage
Inputs Outputs Properties
LOGO! 12/24 RC 12/24 V
DC
8 digital
(1)
4 relays
(10 A)
LOGO! 24 24 V DC 8 digital
(1)
4 solid
state
24V / 0.3A
no clock
LOGO! 24RC
(3)
24 V AC/
24 V DC
8 digital 4 relays
(10A)
LOGO! 230RC
(2)
115...240 V
AC/DC
8 digital 4 relays
(10A)
LOGO! 12/24RCo 12/24 V
DC
8 digital
(1)
4 relays
(10A)
no display unit
no keyboard
LOGO! 24o 24 V DC 8 digital
(1)
4 solid
state
24 V / 0.3A
no display unit
no keyboard
no clock
LOGO! 24RCo
(3)
24 V AC /
24 V DC
8 digital 4 relays
(10A)
no display unit
no keyboard
LOGO! 230RCo
(2)
115...240 V
AC/DC
8 digital 4 relays
(10A)
no display unit
no keyboard
(1): Of those can be used alternatively: 2 analog inputs (0 ... 10V) and 2 fast
inputs.
(2): 230 V AC versions: Two groups consisting of 4 inputs each. Each group
must be connected to the same phase. It is possible to interconnect groups with
a different phase.
(3): The digital inputs can be operated with P or N action.
