LOGO! Manual
A5E00380835-01
108
Function Rem
memory*
Program
memory
Counter
Up/down counter 24 5
Hours counter 24 9
Threshold trigger 16 –
Analog
Analog threshold trigger 16 –
Analog differential trigger 16 –
Analog comparator 24 –
Analog value monitoring 20 –
Analog amplifier 12 –
Analog multiplexer 20 –
Analog ramp 36 –
PI controller 40 2
Others
Latching relay 8 1
Pulse relay 12 1
Message texts 8 –
Softkey 8 2
Shift register 12 1
*: Bytes in the Rem memory area if retentivity is enabled.
Utilization of memory areas
The system indicates that there is insufficient memory
space by not allowing you to add a further block to your
circuit program. LOGO! offers you only the blocks for which
it can provide sufficient memory space. If LOGO! memory
space is insufficient to hold any further blocks you select
from a block list, the system will deny access to this list.
If memory space is fully occupied, optimize your circuit pro-
gram or install a second LOGO!
