If the input PV exceeds the parameter Max, then the
updated value PV is set to the value of Max. If the PV falls
short of the parameter Min, then the updated value PV is
set to the value of Min.
If the input R is set to 1, then the AQ output is reset. As
long as R is set, the input A/M is disabled.
Sampling time
The sampling time is fixed at 500 ms.
Parameter sets
For more information and application examples with appli-
cation-related parameter sets for KC, TI and Dir refer to the
online help for LOGO!Soft Comfort.
Preset of the Par parameter
View in programming mode (example):
B3 1+/
SP !B020
B3 2+/
KC =10.00
TI =01:00
Dir=+
Press
 
Press
 
B3 4+/
A =02.50
B =–00300
p=0
B3 2+/
KC =10.00
TI =01:00
Dir=+
B3 3+/
Mq !B021
Min=–05000
Max=+05000
Press
 
