67
LOGO! Manual
A5E00380835-01
Rule 2
Outputs and inputs
Always create your circuit program by working from the
output to the input.
You can connect an output to several inputs, but not the
same input to several outputs.
Within the same program path you may not connect an
output to an upstream input. For such internal recur-
sions you should interconnect flags or outputs.
Rule 3
Cursor and cursor movement
The following applies when you edit a circuit program:
You can move the cursor when it appears in the form
of an underscore:
– Press , , or to move the cursor in the circuit
program.
– Press OK to change to ”Select connector/block”
– Press ESC to exit programming mode.
You select a connector/block
when the cursor appears as solid square
– Press or to select a connector or a block.
– Confirm with OK.
– Press ESC to return to the previous step.
Rule 4
Planning
Before you start to create a circuit program, you should
either first create design on paper or program LOGO!
directly using LOGO!Soft Comfort.
LOGO! can only save complete and faultless circuit pro-
grams.
Pro
