A.16 Technical data: LOGO! Contact 24/230
LOGO! Contact 24 and LOGO! Contact 230 are switching
modules for direct switching of ohmic loads up to 20 Amps
and motors up to 4 kW (without noise emission, hum-free).
LOGO!
Contact 24
LOGO!
Contact 230
Operating voltage 24 V DC 230 V AC;
50/60 Hz
Switching capacity
Utilization category AC-1: Switching of
ohmic loads at 55°C
Operating current at 400 V
Output with three-phase loads at 400 V
20 A
13 kW
Utilization category AC-2, AC-3: Motor
with slip ring induction/cage armature
Operating current at 400 V
Output with three-phase loads at 400 V
8.4 A
4 kW
Short-circuit protection:
Assignment type 1
Assignment type 2
25 A
10 A
Connecting leads Fine-wire with wire end ferrules
Solid wire
2 x (0.75 to 2.5) mm
2
2 x (1 to 2.5) mm
2
1 x 4 mm
2
Dimensions (WxHxD) 36 x 72 x 55
Ambient temperature -25 ... +55°C
Storage temperature -50 ... +80°C
