Siemens LOGO! - To Remove the LOGO!

LOGO! Manual
A5E00380835-01
26
Removal
To remove the LOGO!:
....... if you have installed only one LOGO! Basic:
Part A
1. Insert a screwdriver into the eyelet at the bottom of the
slide interlock and move the latch downward
2. Swing the LOGO! Basic off the DIN rail.
1
2
1
2
3
4
AB
LOGO! installation and wirin
g
