4.2.2 AND with edge evaluation
Symbol in LOGO!:
The output of an edge triggered AND is only 1 if all inputs
are 1 and if at least one input was low in the previous cy-
cle.
At an unused block input (x): x = 1.
Timing diagram for the AND with edge evaluation
1
Cycle
3
Q
2
123456789
10
4
