A.13 Technical data: CM EIB/KNX
CM EIB/KNX
Mechanical data
Dimensions (WxHxD)
Weight
Installation
36 x 90 x 55 mm
Approx. 107 g
on a 35 mm profile rail
2 module widths
or wall mounting
Power supply
Input voltage 24 V AC/DC
Permissible range –15% ... +10% AC
–15% ... +20% DC
Power consumption from power
supply
max. 25 mA
Power consumption via bus 5 mA
EIB data transmission rate 9600 baud
Connections
Digital inputs (I) virtual max. 16
Digital outputs (Q) virtual max. 12
Analog inputs (AI) virtual max. 8
Analog outputs (AA) virtual max. 2
Group addresses max. 56
Associations max. 56
Climatic conditions
Climatic withstand capability EN 50090-2-2
Ambient operating conditions 0 ... 55 °C natural convection
Storage and transport tempera-
ture
-40 °C ... +70 °C
Relative humidity 95 % at +25 °C (not condensing)
Electrical safety
Type of protection IP 20 (in accordance with EN 60529)
Interference suppression EN 55011 (limit class B)
