LOGO! Manual
A5E00380835-01
3.7 Writing and starting the circuit program
After you have designed a circuit, you want to write it to
your LOGO! . The small example below shows how to do
this.
3.7.1 Selecting programming mode
You have connected the LOGO! to the power supply and
switched it on. The display now shows you the message:
No Program
Press ESC
Switch the LOGO! to programming mode by pressing the
ESC. This will take you to the main menu of the LOGO!:
>Program..
Card..
Setup..
Start
LOGO!’s main menu
The first character in the first line is the ”>” cursor. Press
and to move the ”>” cursor up and down. Move it to ”Pro-
gram..” and confirm with OK. LOGO! opens the program-
ming menu.
>Edit..
Clear Prg
Password
The LOGO!’s programming menu
