Siemens LOGO! - Special Functions List - SF

LOGO! Manual
A5E00380835-01
132
4.4 Special functions list – SF
When you create your circuit program in LOGO!, you find
the special function blocks in the SF list.
You can invert the inputs of SFs individually, i.e. the circuit
program converts a logical “1” at the input into a logical “0”;
a logical “0” it converts into a logical “1”. An example of the
program code found in Chapter 3.7.3.
The table also specifies whether the relevant function can
be set retentivity (Rem). The following SFs are available:
View
inLOGO!
Name of the
special function
Rem
Times
On-delay
(see page 136)
REM
Off-delay
(see page 140)
REM
On-/Off-delay
(see Page 142)
REM
Retentive
on-delay
(see page 144)
REM
Wiping relay (pulse output)
(see page 146)
REM
LOGO! functions
