F Abbreviations
AM Analog module
B1 Block number B1
BN Block Number
C LOGO! device designation: integrated clock
CM Communication Module
Cnt Count = Counter input
Co Connector
Dir Direction (of count, for example)
DM Digital Module
EIB European Installation Bus
EIS EIB Interoperability Standard
En Enable = switching on (e.g. clock generators)
ETS EIB Tool Software
Fre Input for frequency signals to be analyzed
GF Basic Functions
Inv Input for inverting the output signal
KNX Konnex Association Standard for home and building
electronic systems
No Cam (parameter of the timer)
o in LOGO! designations: without display
Par Parameter
R Reset input
R in LOGO! designations: Relay outputs
Ral Reset all = Input for resetting all internal values
S Set (latching relay, for example)
SF Special functions
SU Subunit
T Time = parameter
Trg Trigger (parameter)
0BA5 devices: the latest LOGO! Basic version, described in
this manual.
