LOGO! Manual
A5E00380835-01
254
6.4 Copying data from the program module
(card) to LOGO!
You have a program module (card) that contains your cir-
cuit program. There are two ways to copy it to LOGO!:
Automatically during the startup of LOGO!
(POWER ON) or
by means of the “Card” menu of LOGO!.
Note
If the program on the module/card is protected with the
password X, the copied program in the LOGO! is also pro-
tected with the same password.
Automatic copying during the startup of LOGO!
Proceed as follows:
1. Switch off the power supply to the LOGO!
(POWER OFF)
2. Remove the slot cover.
3. Insert the program module/card into the relevant slot.
4. Switch on the power supply to the LOGO!
LOGO! copies the program from the program module/card
to LOGO!. When LOGO! has finished copying, it opens the
main menu:
>Program..
Card..
Setup..
Start
LOGO! program module (card)
