4.4.2 Off-delay
Short description
When an on-delay is set, the output is reset when the con-
figured time has expired.
Symbol in
LOGO!
Wiring Description
Input Trg You start the off-delay time
with a negative edge (1 to 0
transition) at input Trg (Trig-
ger)
Input R A signal at input R resets
the on-delay time and the
output.
Parameter T is the time that expires af-
ter which the output is
switched off (1 to 0 transi-
tion of the output signal).
Retentivity:
/ = No retentivity
R = The status is retentive.
Output Q Q is set with a signal at in-
put Trg. It holds this state
until T has expired.
Parameter T
Please note the parameter T defaults specified in
Chapter 4.3.2.
The time for parameter T can be based on the actual value
of another, already configured function. You can use the
process variables of the following functions:
Analog comparator (actual value Ax – Ay,
see Chapter 4.4.18)
Analog threshold trigger (actual value Ax,
see Chapter 4.4.16)
LOGO! functions
