Siemens LOGO! - Setup Menu; Transfer Menu

LOGO! Manual
A5E00380835-01
310
>Stop
Set Param
Set..
Prg Name
Transfer menu (ESC / >Stop >Card)
Setup menu (ESC / >Stop >Setup)
> –>Card
>Card–>
>CopyProtect
Copying the program from the program mod-
ule (card) to LOGO! (Chapter 6.4)
Setting the program/copy protection
(Chapter 6.1)
Copying the circuit program from LOGO!
to the program module (card) (Chapter 6.3)
Start menu (RUN)
Everything
clear?
LOGO!
Mo 09:00
2005–01–27
Date/time
max. 10 message texts
Inputs
I:
0.. 123456789
1..0123456789
2..01234
Cursor keys
Q:
0.. 123456789
1..0123456
AI:
1: 00000
2: 01000
3: 00253
Outputs Analog inputs
Parameter assignment menu
>Clock..
>Contrast
>Set Clock
>S/W Time
>Sync
Setting the summertime/wintertime
(Chapter 3.7.13)
Synchronizing the times of LOGO!
Basic and CM EIB/KNX (Chapter
3.7.14)
Setting the display
contrast (Chapter 5.2.2)
Setting the time/date (Chapter
5.2.1)
AI:
4: 00010
5: 00000
6: 00005
AI:
7: 00000
8: 00000
AQ:
1: 00000
2: 01000
M:
0.. 123456789
1..0123456789
2..01234
ESC+C
FlagsAnalog inputs Analog inputs Analog outputs
LOGO! Menu structure
