LOGO! Manual
A5E00380835-01
52
CM EIB/KNX, behaviour on communication failure
LOGO! voltage failure
If there is a power failure of the LOGO! or a disruption in
the communication to the LOGO! master or to the
communication partner on the left-hand side, the
outputs are set to 0. The RUN/STOP LED lights up red
after a second.
LOGO! voltage recovery
LOGO! starts up again, CM EIB/KNX sends the
parameterised states.
CM EIB/KNX voltage failure
All the inputs of the LOGO! master on the EIB are set to
0 by the LOGO! master.
CM EIB/KNX voltage recovery
All the outputs of the LOGO! master on the EIB are
updated. The inputs are read by the EIB depending on
the parameterisation.
Short circuit on the bus or bus interruption
The behaviour can be parameterised in the LOGO!
configuration window of the application program in ETS
(EIB Tool Software). After 5 s, the red LED is set.
Bus recovery
The behaviour can be parameterised in the LOGO!
configuration window.
LOGO! installation and wirin
