Siemens LOGO! - Connecting a Further Expansion Module to an Expansion Module; Connecting an Expansion Module to LOGO! Basic

21
LOGO! Manual
A5E00380835-01
Overview:
Connecting an expansion module to LOGO! Basic
LOGO!
Bi
Expansion modules
Basic
DM8
12/24R,
DM16
24R
DM8
24,
DM16
24
DM 8
24R
DM8
230R,
DM16
230R
AM2,
AM2
PT100,
AM2
AQ
CM
LOGO! 12/24 RC x x x – x x
LOGO! 24 x x x – x x
LOGO! 24 RC x x x – x x
LOGO! 230 RC – – – x x x
LOGO! 12/24RCo x x x – x x
LOGO! 24o x x x – x x
LOGO! 24 RCo x x x – x x
LOGO! 230 RCo – – – x x x
Overview:
Connecting a further expansion module to an expansion
module
Expansion
dl
Further expansion modules
module
DM8
12/24R,
DM16
24R
DM8
24,
DM16
24
DM 8
24R
DM8
230R,
DM16
230R
AM2,
AM2
PT100,
AM2
AQ
CM
DM 8 12/24R,
DM 16 24R
x x x – x x
DM 8 24,
DM 16 24
x x x – x x
LOGO! installation and wirin
g
