A.15 Technical data: LOGO!Power 24 V
LOGO! Power 24 V is a primary-switched power supply
module for LOGO! devices. Two current ranges are avail-
able.
LOGO! Power
24 V / 1.3 A
LOGO! Power
24 V / 2.5 A
Input data
Input voltage 100 ... 240 V AC
Permissible range 85 ... 264 V AC
Permissible mains frequency 47 ... 63 Hz
Voltage failure buffering 40 ms (at 187 V AC)
Input current 0.70 ... 0.35 A 1.22 ... 0.66 A
Inrush current (25°C) < 15 A < 30 A
Device protection Internal
Recommended circuit
breaker (IEC 898) in mains
line
 16 A characteristic B
 10 A characteristic C
Output data
Output voltage
Overall tolerance
Adjustment range
Residual ripple
24 V DC
+/- 3 %
22.2 ... 26.4 V DC
< 200/300 mV
pp
Output current
Overcurrent limiting
1.3 A
typ. 2.0 A
2.5 A
typ. 3.4 A
Efficiency > 82 % > 87 %
Parallel circuit for power in-
crease
Yes
Electromagnetic compatibility
Interference suppression EN 50081-1, Class B to EN 55022
Interference immunity EN 61000-6-2,
EN 61000-4-2/-3/-4/-5/-6/-11
