299
LOGO! Manual
A5E00380835-01
LOGO! Power
12 V / 4.5 A
LOGO! Power
12 V / 1.9 A
Safety
Electrical isolation, primary/
secondary
Yes, SELV (to EN 60950 and EN 50178)
Safety class II
Protection mode IP 20 (to EN 60529)
CE marking
UL/cUL certification
FM approval
GL approval
Yes
Yes; UL 508 / UL 60950
Yes; Class I, Div. 2, T4
Yes
General details
Ambient temperature range –20 ... +55°C, natural convection
Storage and shipping tempe-
rature
–40 ... +70°C
Connections at input One terminal (1 x 2.5
mm2
or 2 x 1.5 mm
2
)
per L1 and N
Connections at output Two terminals (1x.2.5 mm
2
or
2 x 1.5 mm
2
) per + and –
Installation On 35 mm DIN rail, snap-on
Dimensions in mm (WxHxD) 54 x 80 x 55 72 x 90 x 55
Approx. weight 0.2 kg 0.3 kg
Technical data
