Expansion modules
The following expansion modules can be connected to the
LOGO!:
Symbol Name Power supply Inputs Outputs
LOGO! DM 8 12/24R 12/24 V DC 4 digital 4 relays (5A)
LOGO! DM 8 24 24 V DC 4 digital 4 solid state
24V / 0.3A
LOGO! DM 8 24R
(3)
24 V AC/DC 4 digital 4 relays (5A)
LOGO! DM 8 230R 115...240 V AC/DC 4 digital
(1)
4 relays (5A)
LOGO! DM 16 24 24 V DC 8 digital 8 solid state
24V / 0.3A
LOGO! DM 16 24R 24 V DC 8 digital 8 relays (5A)
LOGO! DM 16 230R 115...240 V AC/DC 8 digital
(4)
8 relays (5A)
LOGO! AM 2 12/24 V DC 2 analog
0 ... 10V or 0
... 20mA
(2)
none
LOGO! AM 2 PT100 12/24 V DC 2 Pt100
–50 °C to
+200 °C
none
LOGO! AM 2 AQ 24 V DC none 2 analog
0 ... 10 V DC
(1): Different phases are not allowed within the inputs.
(2): 0 ... 10 V, 0 ... 20 mA can be connected optionally.
(3): Digital inputs can be operated either with P or with N action.
(4): Two groups consisting of 4 inputs each. Each group must be connected to
the same phase. It is possible to interconnect groups with a different phase.
