LOGO! knows the following connectors:
Con-
nectors
LOGO! Basic / Pure
DM
AM AM2AQ
Inputs
LOGO! 230RC/RCo,
LOGO! 24 RC/RCo
Two groups:
I1... I4 and
I5 ... I8
I9 ...
I24
AI1...
AI8
none
LOGO! 12/24RC/
RCo, LOGO! 24/24o
I1... I6, I7, I8
AI1, AI2
I9 ...
I24 AI3...
AI8
Outputs Q1...Q4 Q5 ...
Q16
none V1,
V2
lo Logical ’0’ signals (off)
hi Logical ’1’ signals (on)
x An existing connection that is not used
DM: Digital module
AM: Analog module
