LOGO! Manual
A5E00380835-01
2.2 Installing/removing LOGO!
Dimensions
The LOGO! installation dimensions are compliant with
DIN 43880.
LOGO! can be snap-mounted to 35 mm DIN rails to
EN 50022 or on the wall.
LOGO! width:
LOGO! Basic has a width of 72 mm, which corresponds
with 4 subunits.
LOGO! expansion modules have a width of 36 mm or 72
mm (DM16...), which corresponds with 2 or 4 subunits.
Note
The figure below shows you an example of the installation
and removal of a LOGO! 230 RC and a digital module.
The measures shown apply to all other LOGO! Basic
versions and expansion modules.
!
Warning
Always switch off power before you “remove” and “insert”
an expansion module.
LOGO! installation and wirin
