25
LOGO! Manual
A5E00380835-01
6. Using a screwdriver, push the interlock to the left. In its
end position the slide interlock engages in the LOGO!
Basic.
Repeat steps 3 through 6 to mount further expansion
modules.
Note
The expansion interface on the last expansion module
must be covered.
LOGO! installation and wirin
g
