27
LOGO! Manual
A5E00380835-01
....... if you have connected at least one expansion
module to the LOGO! Basic:
Part B
1. Using a screwdriver, push the integrate slide interlock
to the right
2. Slide the expansion module off towards the right
3. Insert a screwdriver into the eyelet at the bottom of the
slide interlock and lever it downward
4. Swing the expansion module off the profile rail.
Repeat steps 1 to 4 for all other expansion modules.
Note
If you have connected more than one expansion module, it
is advisable to start removal with the last module at the
right-hand side.
Make sure that the slide interlock of the module to be
installed/removed is not engaged in the next module.
LOGO! installation and wirin
