235
LOGO! Manual
A5E00380835-01
Description of the four menu items of the parameter assignment
menu
Stop
You select this command to stop your circuit program and
thus change to the main menu of programming mode. To
do so:
1. To move the ’>’ cursor to ’Stop’: Press or
2. To confirm ’Stop’: Press OK
Stop Prg
>No
Yes
3. To move the ’>’ cursor to ’Yes’: Press or
4. To confirm ’Yes’: Press OK
LOGO! shows the main menu of the programming mode:
>Program..
Card..
Setup..
Start
Set Param
For information on the various parameters, refer to the
Chapters 5.1.1 to 5.1.3.
Set..
For information on the various settings, refer to
Chapter 5.2.
Prg Name
This menu command only allows you to read the name of
your circuit program. It is not possible to modify this name
in parameter assignment mode (see Chapter 3.7.4).
Confi
