LOGO! DM16 24LOGO! DM8 24
Short circuit-proof and over-
load-proof
Yes Yes
Short-circuit current limitation Approx. 1 A Approx. 1 A
Derating none; across the
entire temperature
range
None; across the
entire temperature
range
Short circuit-proof cos 1
Short-circuit proof cos 0.5 to
0.7
Parallel output circuit for
power increase
Not permitted Not permitted
Protection of output relay (if
desired)
Switching rate
Mechanical
Electrical 10 Hz 10 Hz
Ohmic load/lamp load 10 Hz 10 Hz
Inductive load 0.5 Hz 0.5 Hz
(1): When LOGO! 24, LOGO! 24o or LOGO! DM8 24, LOGO! DM16 24 are
switched on, signal 1 is sent to the digital outputs for about 50 microseconds.
Take this into account, especially when using devices that react to short
pulses.
Technical data
