LOGO! Manual
A5E00380835-01
280
LOGO! DM16 24LOGO! DM8 24
Input current at
 Signal 0 < 1.0 mA < 1 mA
> 2 mA
 Signal 1 > 1.5 mA
> 2 mA
Delay time at
 0 to 1 typ. 1.5 ms typ. 1.5 ms
typ. 1.5 ms
 1 to 0 typ. 1.5 ms
yp
Line length (unshielded) 100 m 100 m
Digital outputs
Number 4 8
Output type Transistor,
current-sourcing
(1)
Transistor,
current-sourcing
(1)
Electrical isolation No No
In groups of
Control of a digital input Yes Yes
Output voltage  Supply voltage  Supply voltage
Output current max. 0.3 A max. 0.3 A
Continuous current I
th
Incandescent lamp load
(25000 switching cycles) at
Fluorescent tubes with ballast
(25000 switching cycles)
Fluorescent tubes, conven-
tionally compensated (25000
switching cycles)
Fluorescent tubes, uncom-
pensated (25000 switching
cycles)
Technical data
