Siemens LOGO! - A.5 Technical data: LOGO! DM8 24 and LOGO! DM16 24

279
LOGO! Manual
A5E00380835-01
A.5 Technical data: LOGO! DM8 24 and
LOGO! DM16 24
LOGO! DM8 24 LOGO! DM16 24
Power supply
Input voltage 24 V DC 24 V DC
Permissible range 20.4 ... 28.8 V DC 20.4 ... 28.8 V DC
Reverse polarity protection Yes Yes
Permissible mains frequency
Power consumption from
24 V DC
30 ... 45 mA
0.3 A per output
30 ... 45 mA
0.3 A per output
Voltage failure buffering
Power loss at 24 V 0.8 ... 1.1 W 0.8 ... 1.7 W
Backup of the real-time clock
at 25 C
Accuracy of the real-time
clock
Digital inputs
Number 4 8
Electrical isolation No No
Input voltage L+ L+
 Signal 0 < 5 V DC < 5 V DC
g
 Signal 1 > 8 V DC > 12 V DC
Technical data
