LOGO! Manual
A5E00380835-01
278
LOGO! 24
LOGO! 24o
Incandescent lamp load
(25000 switching cycles) at
Fluorescent tubes with ballast
(25000 switching cycles)
Fluorescent tubes, conven-
tionally compensated (25000
switching cycles)
Fluorescent tubes, uncom-
pensated (25000 switching
cycles)
Short circuit-proof and over-
load-proof
Yes
Short-circuit current limitation Approx. 1 A
Derating none; across the entire temperature range
Short circuit-proof cos 1
Short-circuit proof cos 0.5 to
0.7
Parallel output circuit for
power increase
Not permitted
Protection of output relay (if
desired)
Switching rate
Mechanical
Electrical 10 Hz
Ohmic load/lamp load 10 Hz
Inductive load 0.5 Hz
(1): When LOGO! 24, LOGO! 24o or LOGO! DM8 24, LOGO! DM16 24 are
switched on, signal 1 is sent to the digital outputs for about 50 microseconds.
Take this into account, especially when using devices that react to short
pulses.
Technical data
