277
LOGO! Manual
A5E00380835-01
LOGO! 24
LOGO! 24o
Input current at
 Signal 0 < 1.0 mA (I1...I6)
< 0.05 mA (I7, I8)
 Signal 1
(, )
> 1.5 mA (I1... I6)
> 0.1 mA (I7, I8)
Delay time at
 0 to 1 typ. 1.5 ms
<1.0 ms (I5, I6)
 1 to 0
(, )
typ. 1.5 ms
<1.0 ms (I5, I6)
Line length (unshielded) 100 m
Analog inputs
Number 2 (I7 = AI1, I8 = AI2)
Range 0 ... 10 V DC
input impedance 76 kW
Cycle time for analog value
generation
300 ms
max. input voltage 28.8 V DC
Line length (shielded and
twisted)
10 m
Digital outputs
Number 4
Output type Transistor,
current-sourcing
(1)
Electrical isolation No
In groups of
Control of a digital input Yes
Output voltage  Supply voltage
Output current max. 0.3 A
Continuous current I
th
Technical data
