283
LOGO! Manual
A5E00380835-01
LOGO! 24RC
LOGO! 24RCo
Input current at
Signal 0 < 1.0 mA
Signal 1 > 2.5 mA
Delay time at
0 to 1 typ. 1,5 ms
1 to 0 typ. 15 ms
Line length (unshielded) 100 m
Analog inputs
Number
Range
max. Input voltage
Digital outputs
Number 4
Output type Relay outputs
Electrical isolation Yes
In groups of 1
Control of a digital input Yes
Output voltage
Output current
Continuous current I
th
max. 10 A per relay
Incandescent lamp load
(25000 switching cycles) at
1000 W
Fluorescent tubes with ballast
(25000 switching cycles)
10 x 58 W
Fluorescent tubes, conven-
tionally compensated (25000
switching cycles)
1 x 58 W
Technical data
