LOGO! Manual
A5E00380835-01
138
If the referenced block (B6, in the example) returns a value
that lies out of the valid range, the value is rounded up or
down to the next valid value.
Parameter preset = Actual value of an already programmed
function
How to include the actual value of an actual value of an
already programmed function:
1. Press to move the cursor to the equal sign of parame-
ter T.
T =04:10h
B12 +R
T =04:10h
B12 +R B12 +RB12 +R
Press
twice
T =04:10hT =04:10h
2. Press to change the equal sign into an arrow. If it ex-
ists, the last referenced block and its timebase is shown.
B12 +R
T !B006s
3. Press to move the cursor to the “B” of the shown
block, and then press to select the required block
number.
4. Press to move the cursor to the block’s timebase and
press to select the required timebase.
B12 +R
T !B006m
LOGO! functions
