Preset of the Par parameter
The gain and offset parameters are used to adapt the sen-
sors to the relevant application.
View in programming mode (example):
B3 1+
On =+04000
Off =+02000
Parameter protection mode
On threshold
Off threshold
Press
Decimals in the message text
B3 2
A =01.00
B =+00000
p=2
Offset
Gain
View in parameter assignment mode (example):
B3
On =+04000
Off =+02000
Ax =+05000
On threshold
Off threshold
Q = 1 (Ax > On)
View in the message text (example):
+050.00
Ax, when p = 2
Q = 1 (Ax > On)
