Calculation rule
 When you set a negative differential value n, the On
threshold  Off threshold, and:
Q = 1, if the actual value Ax > On
Q = 0, if the actual value Ax  Off.
See the timing diagram A.
 When you set a positive differential value n, the On
threshold < the Off threshold, and Q = 1, if:
On  actual value Ax < Off.
See the timing diagram B.
Preset of the Par parameter
The gain and offset parameters are used to adapt the sen-
sors to the relevant application.
View in programming mode (example):
B3 1+
On =+04000
n =–02000
Parameter protection mode
On/off threshold
Differential value for the on/off
threshold
Press
Decimals in the message text
B3 2
A =01.00
B =+00000
p=2
Offset
Gain
View in parameter assignment mode (example):
B3
On =+04000
n =–02000
Ax =+05000
On threshold
Differential value for the
off threshold
Q = 1 (Ax > On)
