The thermocouples available have the the following techni-
cal data: –30 to +70C, 0 to 10 VDC.
Application Internal mapping
–30 to +70 C = 0 to 10 V DC 0 to 1000
0 C 300
! Offset = –30
Range of values:
–30 to +70 C = 100
1000
! Gain = 100/1000 = 0.1
On threshold = 15 C Threshold = 15
Off threshold = 5 C Threshold = 5
See also Chapter 4.3.6.
Configuration (example):
B3 1+
On =+00015
Off =+00005
Protection mode
On threshold
Off threshold
Press
Decimals in the message text
(if used)
B3 2
A =00.10
B =–00030
p=0
Offset
Gain
View in parameter assignment mode (example):
B3 1
On =+00015
Off =+00005
On threshold
Off threshold
LOGO! functions
