LOGO! Manual
A5E00380835-01
200
Functional description
Output Q changes its status, i.e. the output is set or reset,
with each 0 to 1 transition at input Trg and if the inputs S
and R = 0.
The signal at input Trg does not influence the special func-
tion when S or R = 1.
You set the pulse relay with a signal at input S, i.e. the out-
put is set hi.
You reset the pulse relay with a signal at input R, i.e. the
output is set lo.
Status diagram
Par Q
n–1
S R Trg Q
n
* 0 0 0 0 0
* 0 0 0 0 –>1 1**
* 0 0 1 0 0
* 0 0 1 0 –>1 0
* 0 1 0 0 1
* 0 1 0 0 –>1 1
RS 0 1 1 0 0
RS 0 1 1 0 –>1 0
SR 0 1 1 0 1
SR 0 1 1 0 –>1 1
* 1 0 0 0 1
* 1 0 0 0 –>1 0**
* 1 0 1 0 0
* 1 0 1 0 –>1 0
* 1 1 0 0 1
* 1 1 0 0 –>1 1
RS 1 1 1 0 0
RS 1 1 1 0 –>1 0
LOGO! functions
