Siemens LOGO! - Page 229

221
LOGO! Manual
A5E00380835-01
Symbol in
LOGO!
DescriptionWiring
Parameter
Level 1 and Level 2:
Levels to be reached
Range of values for
each level:
–10.000 to +20.000
MaxL:
Maximum value that
must not be exceeded.
Range of values:
–10.000 to +20.000
StSp:
Start/Stop offset, value
that is issued for 100ms
after launching the
function and before
reaching the 0 value
(prompted by input St).
Range of values:
0 to 20.000
Rate:
Speed with which
level 1, level 2 or 0 is
reached.
Steps/seconds are
issued.
Range of values:
1 to 10.000
A: Gain
Range of values:
0 to 10.00
B: Offset
Range of values:
10,000
p: Number of decimals
Range of values:
0, 1, 2, 3
LOGO! functions
