Symbol in
LOGO!
DescriptionWiring
Parameter
SP: Set-value assignment
Range of values:
–10.000 to +20.000
KC: Gain
Range of values:
00.00 to 99.99
TI: Integral time
Range of values:
00:01 to 99:59 m
Dir: Action direction of the
controller
Range of values:
+ or –
Mq: Value from AQ with
manual mode
Range of values:
0 to 1000
Min: Minimum value for PV
Range of values:
–10.000 to +20.000
Max: Maximum value for PV
Range of values:
–10.000 to +20.000
A: Gain
Range of values:
10.00
B: Offset
Range of values:
10,000
p: Number of decimals
Range of values:
0, 1, 2, 3
Retentivity:
/ = No retentivity
R = The status is retentive.
LOGO! functions
